Description
Product Type:Aluminum steel Sheet / Plate
Thickness: 0.20mm - 500mm
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,3800mm etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Length:1000mm - 12000mm
Temper:O,H14,H24,H32,H112 Etc;T4,T651 Etc
Material :
1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc.
2000 Series: 2014, 2024, etc.
3000 Series: 3003, 3004, 3005, 3104, 3105, 3A21, etc.
4000 Series: 4045, 4047, 4343, etc.
5000 Series: 5005, 5052, 5083, 5086, 5154, 5182, 5251, 5454, 5754, 5A06, etc.f
6000 Series: 6061, 6063, 6082, 6A02, etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Aluminum sheets possess exceptional corrosion resistance, excellent ductility, and a reflective surface. Weighing approximately one-third that of low-carbon steel, they are ideal for general sheet metal fabrication applications where strength is moderate but weight is a concern. Aluminum sheets are easy to form or bend, and can be processed using hand tools or bending machines. Alternatively, they can be cut using a jigsaw or shearing machine equipped with a suitable blade. The applications of aluminum sheets are wide-ranging, encompassing mold plates, structural components, general engineering, transportation, agriculture, construction, truck bodies, trailer parts, and shipbuilding and yacht manufacturing.
Uion steel Aluminum offers a variety of sizes of 1000, 2000, 3000, 5000, 6000, 7000, and 8000 series aluminum alloy products. Main products include aluminum sheets, aluminum foil, aluminum strip, aluminum coil, aluminum-clad aluminum foil, aluminum patterned sheets, CTP sheets, PS sheets, aluminum electrode capacitor foil, foil materials, deep-drawn sheets, brazed plates, and aluminum patterned sheets.
Specification
Specifications of Aluminum Plate
|
Size in mm
|
Theoretical mass (kg/plate)
|
|
2000 × 1000 × 0.5
|
2.71
|
|
2500 × 1250 × 0.5
|
4.23
|
|
2000 × 1000 × 0.7
|
3.79
|
|
2500 × 1250 × 0.7
|
5.93
|
|
2000 × 1000 × 0.9
|
4.88
|
|
2500 × 1250 × 0.9
|
7.62
|
|
2000 × 1000 × 1.2
|
6.50
|
|
2500 × 1250 × 1.2
|
10.16
|
|
3000 × 1500 × 1.2
|
14.63
|
|
2000 × 1000 × 1.6
|
8.67
|
|
2500 × 1250 × 1.6
|
13.55
|
|
3000 × 1500 × 1.6
|
19.51
|
|
2000 × 1000 × 2.0
|
10.84
|
|
2500 × 1250 × 2.0
|
16.94
|
|
3000 × 1500 × 2.0
|
24.39
|
|
2500 × 1250 × 2.5
|
21.17
|
Standard
Aluminum & Aluminum Alloy Grade
Alloy Grade
1xxx, 2xxx, 3xxx, 4xxx, 5xxx, 6xxx, 7xxx, 8xxx
Tempers
F, 0, Hxxx, Txxxx
|
Alloy Series
|
Alloy
|
Temper
|
Thickness(mm)
|
Width(mm)
|
Major alloying element
|
|
1*** Series
|
1050 1060 1100
|
F, HO, H12, H14,
H16,H18, H22, H24,
H26, H32,H111,
H112, T4, T6, T351, T651
|
1.0-500mm
|
≤3000(max)
|
Pure aluminum (99.0% and greater)
|
|
2*** Series
|
2A12 2024 2017
|
Copper is major addition
|
|
3*** Series
|
3003 3105
|
Manganese is major addition
|
|
4*** Series
|
4045 4047 4343
|
Silicon is major addition
|
|
5*** Series
|
5052 5A02 5A03 5A055754 5083 5086
|
Magnesium is major addition
|
|
6*** Series
|
6061 6063 6082
|
Magnesium and silicon are major additions
|
|
7*** Series
|
7075 7A04 7050 7175
|
Zinc is the major addition
|
|
8*** Series
|
8006 8011 8079
|
Other Alloys
|
|
This is for reference only, product details to the actual subject.
|
Typical Products of Aluminum Plate
-
1100/1060 Aluminum Plate
-
2024 Aluminum Alloy Plate
-
3003/3004 Aluminum Alloy Plate
-
6061/6082 Aluminum Alloy Plate
-
5052 Aluminum Alloy Plate
-
5083 Aluminum Alloy Plate
-
Aluminum Cast Plate For Mold&Tooling
-
Aluminum Tread Sheet/Plate (Aluminum Checker Plate)
Applications of Aluminum Plate
Due to its good performance in physical properties, the aluminium plate is widely used in different industries, some of which include:
|
Industry
|
Alloy
|
|
Aerospace
|
7075 T651 2324 T3/T351J
7150 T7751 2024 T3
7085 T7651 2524 T351
7050 T7451 2017A T4/T451J
7055 T7751 Alcad 2024 T3
|
|
Ship Building
|
6082 T6/T651/Tl12
5754 H112
5052 H32/0
5083 H321/H116/H112/0
5086 0/H116
|
|
Automotive
|
6016 T4/T4P
5182 0
5754 0
6014 T4/T4P
6111 T4/T4P
7075 T4
6451 T4/T4
|
|
Foil Stock (Coil)
|
1235 H14/H16
8011 H14/H16
8079 H14/H16
8021 H14/H16
|
|
Transportation, Construction, Hardware, Bottle Cap, Containers
|
1060 H14/H16/H24/H26/0 6063 T4/T6/T651
3003 0/H1x/H2x 6061 T4/T6/T651
5052 H2x/H3x/0/H111/H112 6082 T4/T6/T651
5083 H3x/H112/H111/0 8011 H14/H16
5086 H3x/H112/H111/0
5182 0/H111/H112/H34
5454 0/H111/H112/H32
|
|
Laptop, Ipad, Mobile Phone, 3C Material, Anodizing
|
5252G H32/H34/H36
6061G T4/T6/T651
6063G T4/T6
5052 H32/H34/H36
5182 H34
|
|
Can Body, Can End, Tap-Strip
|
3004 H19 5182 H19
3104 H19 5052
5182 H48/H19
|
|
Mold and Machinery
|
2024 T351 6061 T651
5052 0/H111/H112 6063 T651
5083 0/H111/H112 7075 T651
6082 T651
|
Advantages of Aluminum Plate
-
Lightweight-approximately one-third the density of steel.
-
High Strength-some alloys can be substantially strengthened by work or by heat treatment.
-
Corrosion Resistance varies depending on the alloy and the best resist marine exposure.
-
Non-toxic-often used in contact with food.
-
Workability-easily formed, machined, and welded.
-
Reflectivity-bright finish options.
-
Non-magnetic and non-sparking.
-
High electrical conductivity.
-
High thermal conductivity.
