Selecting the correct casing dimensions and weight is one of the most important decisions in oil and gas well construction. Casing provides structural support for the wellbore, prevents formation collapse, isolates underground zones, and protects groundwater throughout drilling and production. Choosing the wrong casing size or weight can reduce well integrity, increase operational risks, and lead to higher project costs.
In this guide, you'll find a comprehensive casing dimensions and weight chart based on API 5CT standards, along with practical information on casing sizes, weight designations, and selection considerations for various drilling and production environments.
|
Labels
|
Labels
|
Outside diameter D
|
Nominal linear mass T&C
|
Wall thickness t
|
Inside diameter d
|
Drift diameter
|
Plain end
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Round thread Short
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Round thread Long
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Buttress thread RC
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Buttress thread SCC
|
|
1
|
2.00
|
D (in)
|
lb/ft
|
t (in)
|
d (in)
|
in
|
lb/ft
|
Short
|
Long
|
RC
|
SCC
|
|
1
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
9
|
10
|
11
|
12
|
|
4 1/2
|
9.50
|
4.500
|
9.50
|
0.205
|
4.090
|
3.965
|
9.41
|
4.20
|
|
|
|
|
4 1/2
|
10.50
|
4.500
|
10.50
|
0.224
|
4.052
|
3.927
|
10.24
|
3.80
|
|
5.00
|
2.56
|
|
4 1/2
|
11.60
|
4.500
|
11.60
|
0.250
|
4.000
|
3.875
|
11.36
|
3.40
|
3.80
|
4.60
|
2.16
|
|
4 1/2
|
13.50
|
4.500
|
13.50
|
0.290
|
3.920
|
3.795
|
13.05
|
|
3.20
|
4.00
|
1.56
|
|
4 1/2
|
15.10
|
4.500
|
15.10
|
0.337
|
3.826
|
3.701
|
15.00
|
|
2.80
|
3.20
|
0.76
|
|
5
|
11.50
|
5.000
|
11.50
|
0.220
|
4.560
|
4.435
|
11.24
|
5.40
|
|
|
|
|
5
|
13.00
|
5.000
|
13.00
|
0.253
|
4.494
|
4.369
|
12.84
|
4.80
|
5.80
|
6.60
|
2.42
|
|
5
|
15.00
|
5.000
|
15.00
|
0.296
|
4.408
|
4.283
|
14.88
|
4.20
|
5.20
|
5.80
|
1.62
|
|
5
|
18.00
|
5.000
|
18.00
|
0.362
|
4.276
|
4.151
|
17.95
|
|
4.20
|
4.40
|
0.22
|
|
5
|
21.40
|
5.000
|
21.40
|
0.437
|
4.126
|
4.001
|
21.32
|
|
2.95
|
2.46
|
-1.72
|
|
5
|
23.20
|
5.000
|
23.20
|
0.478
|
4.044
|
3.919
|
23.11
|
|
2.30
|
2.05
|
-2.09
|
|
5
|
24.10
|
5.000
|
24.10
|
0.500
|
4.000
|
3.875
|
24.05
|
|
1.95
|
1.24
|
-2.94
|
|
5 1/2
|
14.00
|
5.500
|
14.00
|
0.244
|
5.015
|
4.887
|
13.71
|
5.40
|
|
|
|
|
5 1/2
|
15.50
|
5.500
|
15.50
|
0.275
|
4.950
|
4.825
|
15.36
|
4.80
|
5.80
|
6.40
|
2.10
|
|
5 1/2
|
17.00
|
5.500
|
17.00
|
0.304
|
4.892
|
4.767
|
16.89
|
4.40
|
5.40
|
5.80
|
1.50
|
|
5 1/2
|
20.00
|
5.500
|
20.00
|
0.361
|
4.778
|
4.653
|
19.83
|
|
4.40
|
4.60
|
0.30
|
|
5 1/2
|
23.00
|
5.500
|
23.00
|
0.415
|
4.670
|
4.545
|
22.56
|
|
3.20
|
3.40
|
0.90
|
|
5 1/2
|
26.80
|
5.500
|
26.80
|
0.500
|
4.500
|
4.375
|
26.72
|
|
|
|
|
|
5 1/2
|
29.70
|
5.500
|
29.70
|
0.562
|
4.376
|
4.251
|
29.67
|
|
|
|
|
|
5 1/2
|
32.60
|
5.500
|
32.60
|
0.625
|
4.250
|
4.125
|
32.57
|
|
|
|
|
|
5 1/2
|
35.30
|
5.500
|
35.30
|
0.687
|
4.126
|
4.001
|
35.35
|
|
|
|
|
|
5 1/2
|
38.00
|
5.500
|
38.00
|
0.750
|
4.000
|
3.875
|
38.08
|
|
|
|
|
|
5 1/2
|
40.50
|
5.500
|
40.50
|
0.812
|
3.876
|
3.751
|
40.69
|
|
|
|
|
|
5 1/2
|
43.10
|
5.500
|
43.10
|
0.875
|
3.750
|
3.625
|
43.26
|
|
|
|
|
|
6 5/8
|
20.00
|
6.625
|
20.00
|
0.288
|
6.049
|
5.924
|
19.51
|
11.00
|
13.60
|
14.40
|
2.38
|
|
6 5/8
|
24.00
|
6.625
|
24.00
|
0.352
|
5.921
|
5.796
|
23.60
|
9.60
|
12.00
|
12.60
|
0.58
|
|
6 5/8
|
28.00
|
6.625
|
28.00
|
0.417
|
5.791
|
5.666
|
27.67
|
|
10.20
|
10.60
|
-1.42
|
|
6 5/8
|
32.00
|
6.625
|
32.00
|
0.475
|
5.675
|
5.550
|
31.23
|
|
8.80
|
9.00
|
-3.02
|
|
7
|
17.00
|
7.000
|
17.00
|
0.231
|
6.538
|
6.413
|
16.72
|
10.00
|
|
|
|
|
7
|
20.00
|
7.000
|
20.00
|
0.272
|
6.456
|
6.331
|
19.56
|
9.40
|
|
|
|
|
7
|
23.00
|
7.000
|
23.00
|
0.317
|
6.366
|
6.250
|
22.65
|
8.00
|
10.40
|
11.00
|
160
|
|
7
|
23.00
|
7.000
|
23.00
|
0.317
|
6.366
|
6.241
|
22.65
|
8.00
|
10.40
|
11.00
|
1.60
|
|
7
|
26.00
|
7.000
|
26.00
|
0.362
|
6.276
|
6.151
|
25.69
|
7.20
|
9.40
|
9.60
|
0.20
|
|
7
|
29.00
|
7.000
|
29.00
|
0.408
|
6.184
|
6.059
|
28.75
|
|
8.00
|
8.20
|
1.20
|
|
7
|
32.00
|
7.000
|
32.00
|
0.453
|
6.094
|
6.000
|
31.70
|
|
6.60
|
6.80
|
2.60
|
|
7
|
32.00
|
7.000
|
32.00
|
0.453
|
6.094
|
5.969
|
31.70
|
|
6.60
|
6.80
|
2.60
|
|
7
|
35.00
|
7.000
|
35.00
|
0.498
|
6.004
|
5.879
|
34.61
|
|
5.60
|
5.60
|
3.80
|
|
7
|
38.00
|
7.000
|
38.00
|
0.540
|
5.920
|
5.795
|
37.29
|
|
4.40
|
4.20
|
5.20
|
|
7
|
42.70
|
7.000
|
42.70
|
0.625
|
5.750
|
5.625
|
42.59
|
|
|
|
|
|
7
|
46.40
|
7.000
|
46.40
|
0.687
|
5.625
|
5.500
|
46.36
|
|
|
|
|
|
7
|
50.10
|
7.000
|
50.10
|
0.750
|
5.500
|
5.375
|
50.11
|
|
|
|
|
|
7
|
53.60
|
7.000
|
53.60
|
0.812
|
5.376
|
5.251
|
53.71
|
|
|
|
|
|
7
|
57.10
|
7.000
|
57.10
|
0.875
|
5.376
|
5.125
|
57.29
|
|
|
|
|
|
Labels
|
Labels
|
Outside diameter D
|
Nominal linear mass T&C
|
Wall thickness t
|
Inside diameter d
|
Drift diameter
|
Plain end
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Round thread Short
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Round thread Long
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Buttress thread RC
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Buttress thread SCC
|
|
1
|
2.00
|
D (in)
|
lb/ft
|
t (in)
|
d (in)
|
in
|
lb/ft
|
Short
|
Long
|
RC
|
SCC
|
|
1
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
9
|
10
|
11
|
12
|
|
7 5/8
|
24.00
|
7.625
|
24.00
|
0.300
|
7.025
|
6.900
|
23.49
|
15.80
|
|
|
|
|
7 5/8
|
26.40
|
7.625
|
26.40
|
0.328
|
6.969
|
6.844
|
25.59
|
15.20
|
19.00
|
20.60
|
6.21
|
|
7 5/8
|
29.70
|
7.625
|
29.70
|
0.375
|
6.875
|
6.750
|
29.06
|
|
17.40
|
18.80
|
4.41
|
|
7 5/8
|
33.70
|
7.625
|
33.70
|
0.430
|
6.765
|
6.640
|
33.07
|
|
15.80
|
17.00
|
2.61
|
|
7 5/8
|
39.00
|
7.625
|
39.00
|
0.500
|
6.625
|
6.500
|
38.08
|
|
13.60
|
14.60
|
0.21
|
|
7 5/8
|
42.80
|
7.625
|
42.80
|
0.562
|
6.501
|
6.376
|
42.43
|
|
12.01
|
11.39
|
-3.01
|
|
7 5/8
|
45.30
|
7.625
|
45.30
|
0.595
|
6.435
|
6.310
|
44.71
|
|
11.04
|
11.04
|
-3.36
|
|
7 5/8
|
47.10
|
7.625
|
47.10
|
0.625
|
6.375
|
6.250
|
46.77
|
|
10.16
|
9.23
|
-5.17
|
|
7 5/8
|
51.20
|
7.625
|
51.20
|
0.687
|
6.251
|
6.126
|
50.95
|
|
|
|
|
|
7 5/8
|
55.30
|
7.625
|
55.30
|
0.750
|
6.125
|
6.000
|
55.12
|
|
|
|
|
|
7 3/4
|
46.10
|
7.750
|
46.10
|
0.595
|
6.560
|
6.500
|
45.51
|
|
|
|
|
|
7 3/4
|
46.10
|
7.750
|
46.10
|
0.595
|
6.560
|
6.435
|
45.51
|
|
|
|
|
|
8 5/8
|
24.00
|
8.625
|
24.00
|
0.264
|
8.097
|
7.972
|
23.60
|
23.60
|
|
|
|
|
8 5/8
|
28.00
|
8.625
|
28.00
|
0.304
|
8.017
|
7.892
|
27.04
|
22.20
|
|
|
|
|
8 5/8
|
32.00
|
8.625
|
32.00
|
0.352
|
7.921
|
7.875
|
31.13
|
20.80
|
27.60
|
28.30
|
6.03
|
|
8 5/8
|
32.00
|
8.625
|
32.00
|
0.352
|
7.921
|
7.796
|
31.13
|
20.80
|
27.60
|
28.20
|
6.03
|
|
8 5/8
|
36.00
|
8.625
|
36.00
|
0.400
|
7.825
|
7.700
|
35.17
|
19.40
|
25.60
|
26.20
|
4.03
|
|
8 5/8
|
40.00
|
8.625
|
40.00
|
0.450
|
7.725
|
7.625
|
39.33
|
|
23.80
|
24.20
|
2.03
|
|
8 5/8
|
40.00
|
8.625
|
40.00
|
0.450
|
7.725
|
7.600
|
39.33
|
|
23.80
|
24.20
|
2.03
|
|
8 5/8
|
44.00
|
8.625
|
44.00
|
0.500
|
7.625
|
7.500
|
43.43
|
|
21.80
|
22.20
|
0.03
|
|
8 5/8
|
49.00
|
8.625
|
49.00
|
0.557
|
7.511
|
7.286
|
48.04
|
|
19.60
|
19.80
|
-2.37
|
|
9 5/8
|
32.30
|
9.625
|
32.30
|
0.312
|
9.001
|
8.845
|
31.06
|
24.40
|
|
|
|
|
9 5/8
|
36.00
|
9.625
|
36.00
|
0.352
|
8.921
|
8.876
|
34.89
|
23.00
|
32.00
|
31.00
|
6.48
|
|
9 5/8
|
40.00
|
9.625
|
40.00
|
0.395
|
8.835
|
8.750
|
38.97
|
21.40
|
30.00
|
29.00
|
4.48
|
|
9 5/8
|
40.00
|
9.625
|
40.00
|
0.395
|
8.835
|
8.679
|
38.97
|
21.40
|
30.00
|
29.00
|
4.48
|
|
9 5/8
|
43.50
|
9.625
|
43.50
|
0.435
|
8.755
|
8.599
|
42.73
|
|
28.20
|
27.20
|
2.68
|
|
9 5/8
|
47.00
|
9.625
|
47.00
|
0.472
|
8.681
|
8.525
|
46.18
|
|
26.60
|
25.60
|
1.08
|
|
9 5/8
|
53.50
|
9.625
|
53.50
|
0.545
|
8.535
|
8.500
|
52.90
|
|
23.40
|
22.40
|
-2.12
|
|
9 5/8
|
53.50
|
9.625
|
53.50
|
0.545
|
8.535
|
8.379
|
52.90
|
|
23.40
|
22.40
|
-2.12
|
|
9 5/8
|
58.40
|
9.625
|
58.40
|
0.595
|
8.435
|
8.375
|
57.44
|
|
21.50
|
20.13
|
-4.40
|
|
9 5/8
|
58.40
|
9.625
|
58.40
|
0.595
|
8.435
|
8.279
|
57.44
|
|
21.50
|
20.13
|
-4.40
|
|
9 5/8
|
59.40
|
9.625
|
59.40
|
0.609
|
8.407
|
8.251
|
58.70
|
|
|
|
|
|
9 5/8
|
64.90
|
9.625
|
64.90
|
0.672
|
8.281
|
8.125
|
64.32
|
|
|
|
|
|
9 5/8
|
70.30
|
9.625
|
70.30
|
0.734
|
8.157
|
8.001
|
69.76
|
|
|
|
|
|
9 5/8
|
75.60
|
9.625
|
75.60
|
0.797
|
8.031
|
7.875
|
75.21
|
|
|
|
|
|
10 3/4
|
32.75
|
10.750
|
32.75
|
0.279
|
10.192
|
10.036
|
31.23
|
29.00
|
|
|
|
|
10 3/4
|
40.50
|
10.750
|
40.50
|
0.350
|
10.050
|
9.894
|
38.91
|
26.40
|
|
34.40
|
7.21
|
|
10 3/4
|
45.50
|
10.750
|
45.50
|
0.400
|
9.950
|
9.875
|
44.26
|
24.40
|
|
31.80
|
4.61
|
|
10 3/4
|
45.50
|
10.750
|
45.50
|
0.400
|
9.950
|
9.794
|
44.26
|
24.40
|
|
31.80
|
4.61
|
|
10 3/4
|
51.00
|
10.750
|
51.00
|
0.450
|
9.850
|
9.694
|
49.55
|
22.60
|
|
29.40
|
2.21
|
|
10 3/4
|
55.50
|
10.750
|
55.50
|
0.495
|
9.760
|
9.625
|
54.26
|
20.80
|
|
27.00
|
-0.19
|
|
10 3/4
|
55.50
|
10.750
|
55.50
|
0.495
|
9.760
|
9.604
|
54.26
|
20.80
|
|
27.00
|
-0.19
|
|
10 3/4
|
60.70
|
10.750
|
60.70
|
0.545
|
9.660
|
9.504
|
59.45
|
18.80
|
|
24.40
|
|
|
10 3/4
|
65.70
|
10.750
|
65.70
|
0.595
|
9.560
|
9.404
|
64.59
|
16.80
|
|
22.00
|
|
|
10 3/4
|
73.20
|
10.750
|
73.20
|
0.672
|
9.406
|
9.250
|
72.40
|
|
|
|
|
|
10 3/4
|
79.20
|
10.750
|
79.20
|
0.734
|
9.282
|
9.126
|
78.59
|
|
|
|
|
|
10 3/4
|
85.30
|
10.750
|
85.30
|
0.797
|
9.156
|
|
|
|
|
|
|
|
Labels
|
Labels
|
Outside diameter D
|
Nominal linear mass T&C
|
Wall thickness t
|
Inside diameter d
|
Drift diameter
|
Plain end
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Round thread Short
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Round thread Long
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Buttress thread RC
|
Calculated mass C: Mass gain or loss due to end finishing (lb) - Buttress thread SCC
|
|
1
|
2
|
D (in)
|
lb/ft
|
t (in)
|
d (in)
|
in
|
lb/ft
|
Short
|
Long
|
RC
|
SCC
|
|
1
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
9
|
10
|
11
|
12
|
|
11 3/4
|
42
|
11.75
|
42
|
0.333
|
11.084
|
11
|
40.64
|
29.6
|
|
|
|
|
11 3/4
|
42
|
11.75
|
42
|
0.333
|
11.084
|
10.928
|
40.64
|
29.6
|
|
|
|
|
11 3/4
|
47
|
11.75
|
47
|
0.375
|
11
|
10.844
|
45.6
|
27.6
|
|
35.8
|
|
|
11 3/4
|
54
|
11.75
|
54
|
0.435
|
10.88
|
10.724
|
52.62
|
25
|
|
32.4
|
|
|
11 3/4
|
60
|
11.75
|
60
|
0.489
|
10.772
|
10.625
|
58.87
|
22.6
|
|
29.6
|
|
|
11 3/4
|
60
|
11.75
|
60
|
0.489
|
10.772
|
10.616
|
58.87
|
22.6
|
|
29.6
|
|
|
11 3/4
|
65
|
11.75
|
65
|
0.534
|
10.682
|
10.625
|
64.03
|
|
|
|
|
|
11 3/4
|
65
|
11.75
|
65
|
0.534
|
10.682
|
10.625
|
64.03
|
|
|
|
|
|
11 3/4
|
71
|
11.75
|
71
|
0.582
|
10.586
|
10.43
|
69.48
|
|
|
|
|
|
13 3/8
|
48
|
13.375
|
48
|
0.33
|
12.715
|
12.559
|
46.02
|
33.2
|
|
|
|
|
13 3/8
|
54.5
|
13.375
|
54.5
|
0.38
|
12.615
|
12.459
|
52.79
|
30.8
|
|
40.2
|
|
|
13 3/8
|
61
|
13.375
|
61
|
0.43
|
12.515
|
12.359
|
59.5
|
28.4
|
|
36.8
|
|
|
13 3/8
|
68
|
13.375
|
68
|
0.48
|
12.415
|
12.259
|
66.17
|
25.8
|
|
33.6
|
|
|
13 3/8
|
72
|
13.375
|
72
|
0.514
|
12.347
|
12.25
|
70.67
|
24.2
|
|
31.6
|
|
|
13 3/8
|
72
|
13.375
|
72
|
0.514
|
12.347
|
12.191
|
70.67
|
24.2
|
|
31.6
|
|
|
16
|
65
|
16
|
65
|
0.375
|
15.25
|
15.062
|
62.64
|
42.6
|
|
|
|
|
16
|
75
|
16
|
75
|
0.438
|
15.124
|
14.936
|
72.86
|
38.2
|
|
45.6
|
|
|
16
|
84
|
16
|
84
|
0.495
|
15.01
|
14.822
|
82.05
|
34.2
|
|
39.6
|
|
|
16
|
109
|
16
|
109
|
0.656
|
14.688
|
14.5
|
107.6
|
|
|
|
|
|
18 5/8
|
87.5
|
18.625
|
87.5
|
0.435
|
17.755
|
17.567
|
84.59
|
73.6
|
|
86.4
|
|
|
20
|
94
|
20
|
94
|
0.438
|
19.124
|
18.936
|
91.59
|
47
|
61.2
|
54.8
|
|
|
20
|
106.5
|
20
|
106.5
|
0.5
|
19
|
18.812
|
104.23
|
41.6
|
54.8
|
48.4
|
|
|
20
|
133
|
20
|
133
|
0.635
|
18.73
|
18.542
|
131.45
|
30
|
40.6
|
35.2
|
|
Conclusion
Understanding a casing dimensions and weight chart is essential for designing safe, efficient, and cost-effective oil and gas wells. Whether your project involves onshore drilling, offshore platforms, shale gas development, or deep wells, choosing the correct casing dimensions helps improve well integrity, reduce operational risks, and ensure long-term reliability.
At Union Steel Industry, we supply high-quality API 5CT casing pipes in a wide range of sizes, weights, steel grades, and premium connections. Every casing product undergoes strict quality control, dimensional inspection, and mechanical testing to ensure compliance with international standards and demanding field conditions.
FAQ
1. What is a casing dimensions and weight chart?
It is a reference table showing API casing sizes, outside diameters, wall thicknesses, and nominal weights.
2. Which standard covers casing dimensions?
Most oilfield casing dimensions are specified according to API 5CT.
3. How is casing weight expressed?
Casing weight is typically measured in lb/ft or kg/m, depending on the standard used.
4. Why is casing weight important?
It affects the pipe's strength, collapse resistance, and suitability for different well conditions.
5. What are the most common casing sizes?
Common sizes include 4½", 5½", 7", 9⅝", 13⅜", and 20", depending on the drilling application.
6. How do I choose the right casing size?
Select the size based on well depth, pressure requirements, formation conditions, and API specifications.
English
Español
Tel : +86-18565811709
Email :
News
