Description
Soft seat ball valve & Metal seat ball valve
Floating, DBB .DIB Design for Option
•Size: 4" ~60"
•Pressure Rating: CL150~CL2500, 1000psi ~6000psi
•Connection end: SW, Thread, FF, RF, RTJ, BW, Wafer
•Body Material: Body Materials Carbon Steel,Stainless Steel, Alloy steel, Duplex SS etc. Optional materials on request.
•Design Standard: ISO 17292, AP| 608, API 6D
•Test: API 598, ISO 5208, API 6D
•Flange End: ASME B16.5, ASME B16.47
•Welding End: ASME B16.25
•Face to Face: ASME B16.10, AP| 6D
•Sour Service: NACE MR 0175
•Fire safety: API 607, API 6FA
•Anti-static Design, Anti Blow-Out
•Operation: Lever, Gear, pneumatic, Electric, Hydraulic, etc.
•Application conditions: The ball valve has the characteristics of low flow resistance, which can be applied to almost all industrial pipeline systems, especially in the case of conveying liquids and gases. Ball valves can be opened and closed quickly, can quickly cut off fluid and gas flow, with good sealing and corrosion resistance. Soft seat or hard seat ball valves can be selected according to temperature and medium conditions.
Specification
API ball valve
Production enforce standard
Product
specification
|
Design spec
|
Face to face
|
Flange end
|
Test &check
|
Marking
|
Supply
|
API608
API6D
|
ANSI B16.10
API6D
|
ANSI B16.5
|
API598
API 6D
|
MSS SP-25
API 6D
|
API 608
API6D
|
Chief property and specification
|
Nominal pressure
|
150Lb
|
300Lb
|
400Lb
|
600Lb
|
|
Shell test pressure
|
3.1
|
7.5
|
10.2
|
15.0
|
|
Seal test
|
2.2
|
5.5
|
7.48
|
11.C
|
|
Seal test
|
0.5~0.7
|
|
Applicable medium
|
C
Water,oil,steam
|
P
Nitric acid
|
R
Acetic acid
|
Material for main parts
|
Parts name
|
WCB
|
CF8
|
CF3
|
CF8M
|
CF3M
|
|
Body &body cap
|
A216-WCB
|
A315-CF8
|
A35-CF3
|
A351-CF8M
|
A351-CE³M
|
|
Ball
|
B2-B8
|
A105-1025
|
A182-F304L
|
A182-F304L
|
A132-F316
|
A182-F316L
|
|
B8以上
|
A216-WCB
|
A351-CF8N
|
A351-CF3
|
A351-CF8M
|
A351-CF3M
|
|
Steam
|
A182-F6a
|
A182-F304
|
A182-F304L
|
A182-F336
|
A182-F316L
|
|
Seat
|
PTFE/Reinforced PTFE/Nyion
|
|
Ceat retaine
|
A105-1025
|
A182-F304
|
A182-F304L
|
A182-F316
|
A182-F316L
|
|
Spring
|
3yc-7/17-49H
|
|
O-ring
|
NBR
|
Viton
|
|
Stud
|
A193-B7
|
A193-B8
|
|
Nut
|
A194-2H
|
A194-8
|
A1-6B(3)41,(3)47,(3)61,(3)67F
Main external and connection dimension
|
CLASS 150 A1B(3)41,(3)47,(3)61,(3)67F(N.PPL).(P.R.V)
|
Unit:mm
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
Remark
|
|
d
|
L-RF
|
L-BW
|
D
|
D1
|
D2
|
|
|
N-中
|
H1
|
H2
|
Do
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4“
|
102
|
229
|
305
|
229
|
190.5
|
157
|
23.9
|
1.6
|
8-19
|
|
178
|
700
|
33.0
|
|
5"
|
127
|
356
|
|
254
|
216
|
186
|
23.9
|
1.6
|
8-22
|
|
252
|
100
|
58.0
|
|
6"
|
52
|
394
|
457
|
279
|
241.5
|
216
|
54.5
|
1.6
|
8-22
|
|
272
|
1100
|
93.0
|
|
8"
|
203
|
457
|
521
|
343
|
298.5
|
27(
|
58.6
|
1.6
|
8-22
|
|
342
|
500
|
60.C
|
|
8"
|
203
|
457
|
521
|
343
|
298.5
|
270
|
28.6
|
1.6
|
8-22
|
|
398
|
600
|
180.0
|
Fixing
ball
|
|
10“
|
254
|
533
|
559
|
406
|
362
|
324
|
30.2
|
1.6
|
12-25
|
335
|
495
|
600
|
240.0
|
|
12"
|
305
|
610
|
635
|
482.6
|
A31.8
|
381
|
31.8
|
1.6
|
2-25
|
385
|
580
|
80C
|
390.0
|
|
14"
|
337
|
686
|
762
|
535
|
476
|
412.8
|
35
|
1.6
|
12-29
|
430
|
625
|
800
|
510.0
|
|
16"
|
387
|
162
|
838
|
597
|
539.5
|
469.9
|
36.6
|
1.6
|
16-29
|
470
|
720
|
800
|
750.0
|
|
20”
|
489
|
914
|
991
|
698
|
635
|
58.2
|
42.9
|
1.6
|
20-32
|
590
|
840
|
800
|
1190
|
|
24"
|
591
|
1067
|
1143
|
813
|
749.5
|
692.2
|
47.8
|
1.6
|
20-35
|
700
|
1050
|
800
|
2100
|
|
26"
|
686
|
1245
|
1346
|
927.1
|
836.6
|
800.1
|
71.4
|
1.6
|
28-35
|
780
|
1150
|
800
|
3000
|
|
CLASS 300 A3B(3)41,(3)47,(3)67F(N.PPL).(P.R.V)
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
|
|
|
|
|
d
|
-RF
_
|
L-BW
|
D
|
D1
|
D2
|
|
|
N-φ
|
H1
|
H2
|
Do
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4"
|
102
|
305
|
305
|
254
|
200
|
157
|
31.8
|
1.6
|
8-22
|
|
178
|
700
|
55.0
|
|
5"
|
127
|
381
|
|
279
|
235
|
186
|
35
|
1.6
|
8-22
|
|
252
|
100
|
81.0
|
|
6"
|
52
|
403
|
457
|
318
|
270
|
216
|
36.5
|
1.6
|
12-22
|
|
272
|
1100
|
118.0
|
|
8"
|
203
|
502
|
521
|
381
|
330
|
270
|
41.3
|
1.6
|
12-25
|
|
342
|
500
|
200.00
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8"
|
203
|
502
|
521
|
381
|
330
|
270
|
41.3
|
1.6
|
12-25
|
|
398
|
600
|
220.2
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
10"
|
254
|
568
|
559
|
444
|
387.5
|
324
|
17.7
|
1.6
|
16-29
|
335
|
495
|
600
|
365
|
|
12"
|
305
|
648
|
635
|
520.8
|
451
|
381
|
50.8
|
1.6
|
6-32
|
385
|
580
|
800
|
530
|
|
14"
|
337
|
762
|
762
|
584.2
|
514.5
|
412.8
|
53.8
|
1.6
|
20-32
|
430
|
625
|
800
|
740
|
|
16"
|
387
|
838
|
838
|
647.8
|
571.5
|
469.9
|
57.2
|
1.6
|
20-35
|
470
|
720
|
800
|
1030
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
20"
|
489
|
991
|
991
|
774.8
|
685.8
|
58.2
|
63.5
|
1.6
|
24-35
|
590
|
840
|
800
|
1540
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
24"
|
591
|
143
|
143
|
914.4
|
812.8
|
692.2
|
69.8
|
1.6
|
24-41
|
700
|
1050
|
800
|
2600
|
|
28"
|
686
|
1346
|
1346
|
1035
|
939.8
|
800.1
|
85.9
|
1.6
|
28-44.5
|
780
|
150
|
800
|
3900
|
|
A1-6B(3)41,(3)47,(3)61,(3)67F
|
|
Main external and connection dimension
|
|
CLASS 400 A4B(3)41,(3)47,(3)67F(N.PPL).(P.R.V)
|
|
DN
|
Main external and connection dimension
|
|
|
d
|
L-RF
|
L-BW
|
|
|
|
|
|
|
4"
|
102
|
406
|
406
|
|
|
|
|
|
|
6“
|
152
|
495
|
495
|
|
|
|
|
|
|
8"
|
203
|
597
|
597
|
|
10"
|
254
|
673
|
673
|
|
|
|
|
|
|
12"
|
305
|
762
|
762
|
|
|
|
|
|
|
14"
|
337
|
826
|
826
|
|
|
|
|
|
|
16"
|
387
|
902
|
902
|
|
20”
|
489
|
1054
|
1054
|
|
|
|
|
|
|
24"
|
591
|
1232
|
1232
|
|
|
|
|
|
|
26”
|
686
|
1397
|
1397
|
|
CLASS 600 A6B(3)41,(3)47,(3)67F(N.PPL).(P.R.V)
|
|
Unit:mm
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
Remark
|
|
d
|
L-RF
|
L-BW
|
D
|
D1
|
D2
|
|
|
N-Φ
|
H1
|
H2
|
Do
|
|
4"
|
102
|
432
|
432
|
273
|
216
|
157.2
|
38
|
6.4
|
8-25
|
|
178
|
1100
|
76
|
|
6"
|
152
|
559
|
559
|
355.6
|
282.1
|
216
|
47.2
|
6.4
|
12-29
|
250
|
300
|
600
|
127
|
|
8"
|
203
|
660
|
660
|
419.5
|
349.2
|
269.8
|
55.7
|
6.4
|
12-32
|
294
|
374
|
800
|
350
|
Fixing
ball
|
|
10"
|
254
|
787
|
787
|
508
|
431.8
|
324
|
63.5
|
6.4
|
16-35
|
370
|
445
|
800
|
660
|
|
12"
|
305
|
838
|
838
|
559
|
489
|
381
|
66.5
|
6.4
|
20-35
|
420
|
515
|
800
|
820
|
|
14"
|
337
|
889
|
889
|
603.2
|
527
|
413
|
69.8
|
6.4
|
20-38
|
460
|
550
|
800
|
1130
|
|
16"
|
387
|
991
|
991
|
686
|
603.2
|
470
|
76.2
|
6.4
|
20-41
|
505
|
615
|
800
|
1550
|
|
20”
|
489
|
1194
|
1194
|
818
|
724
|
584.2
|
89
|
6.4
|
24-445
|
630
|
810
|
800
|
2800
|
|
24"
|
591
|
1394
|
1394
|
940
|
838.2
|
692.2
|
101.6
|
6.4
|
24-51
|
825
|
1010
|
800
|
5300
|
|
26”
|
686
|
1549
|
1549
|
1073
|
965.2
|
800
|
111.3
|
6.4
|
28-55
|
970
|
1180
|
800
|
6500
|
Floating ball valve
|
Main external and connection dimension
|
Unit:mm
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
L
|
D
|
D1
|
Dz
|
b
|
Z-d
|
H
|
W
|
|
Q41F-16C Q41F-16P Q641F-16C Q641F-16P Q9B41F-16C Q9B41F-16P
|
|
15
|
130
|
95
|
65
|
45
|
14
|
4-14
|
78
|
140
|
3
|
|
20
|
140
|
105
|
75
|
55
|
14
|
4-14
|
84
|
160
|
4
|
|
25
|
150
|
115
|
85
|
65
|
14
|
4-14
|
95
|
180
|
5
|
|
32
|
165
|
135
|
100
|
78
|
16
|
4-18
|
150
|
250
|
9
|
|
40
|
180
|
145
|
110
|
85
|
16
|
4-18
|
150
|
300
|
11
|
|
50
|
203
|
160
|
125
|
100
|
16
|
4-18
|
170
|
350
|
15
|
|
65
|
222
|
180
|
145
|
120
|
18
|
4-18
|
195
|
350
|
19
|
|
80
|
241
|
195
|
160
|
135
|
20
|
8-18
|
215
|
400
|
27
|
|
100
|
305
|
215
|
180
|
155
|
20
|
8-18
|
250
|
500
|
38
|
|
125
|
356
|
245
|
210
|
185
|
22
|
8-18
|
265
|
600
|
58
|
|
150
|
394
|
280
|
240
|
210
|
24
|
8-23
|
270
|
800
|
81
|
|
200
|
457
|
335
|
295
|
265
|
26
|
12-23
|
330
|
800
|
95
|
|
250
|
533
|
405
|
355
|
320
|
30
|
12-25
|
450
|
1300
|
140
|
Q41/341/641/941P-25~64(P)
Main external and connection dimension Unit:mm
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
|
D
|
D1
|
D2
|
b
|
Z-c
|
H
|
W
|
|
Q41F-25 Q41F-25P Q641F-25 Q641F-25P Q9B41F-25 Q9B41F-25P
|
|
15
|
140
|
95
|
65
|
45
|
16
|
4-14
|
103
|
100
|
3
|
|
20
|
152
|
105
|
75
|
55
|
16
|
4-14
|
112
|
160
|
4
|
|
25
|
165
|
115
|
85
|
65
|
16
|
4-14
|
123
|
160
|
6
|
|
32
|
178
|
135
|
100
|
78
|
18
|
4-18
|
150
|
250
|
10
|
|
40
|
190
|
145
|
110
|
85
|
18
|
4-18
|
156
|
250
|
14
|
|
50
|
216
|
160
|
125
|
100
|
20
|
4-18
|
172
|
350
|
20
|
|
65
|
241
|
180
|
145
|
120
|
22
|
8-18
|
197
|
350
|
25
|
|
80
|
283
|
195
|
160
|
135
|
22
|
8-18
|
222
|
450
|
30
|
|
100
|
305
|
230
|
190
|
160
|
24
|
8-23
|
253
|
450
|
40
|
|
125
|
381
|
270
|
220
|
188
|
28
|
8-25
|
275
|
600
|
65
|
|
150
|
403
|
300
|
250
|
218
|
30
|
8-25
|
286
|
800
|
85
|
|
200
|
502
|
360
|
310
|
278
|
34
|
12-25
|
340
|
1200
|
100
|
|
250
|
568
|
425
|
370
|
332
|
36
|
12-30
|
470
|
1400
|
165
|
|
Q41F-40 Q41F-40P Q341F-40 Q341F-40P Q641F-40 Q641F-40P Q9B41F-40 Q9B41F-40P
|
|
15
|
140
|
95
|
65
|
45
|
16
|
4-14
|
103
|
100
|
3
|
|
20
|
152
|
105
|
75
|
55
|
16
|
4-14
|
112
|
160
|
|
|
25
|
165
|
115
|
85
|
65
|
16
|
4-14
|
123
|
160
|
6
|
|
32
|
178
|
135
|
100
|
78
|
18
|
4-18
|
150
|
250
|
10
|
|
40
|
190
|
145
|
110
|
85
|
18
|
4-18
|
156
|
250
|
14
|
|
50
|
216
|
160
|
125
|
100
|
20
|
4-18
|
172
|
350
|
20
|
|
65
|
241
|
180
|
145
|
120
|
22
|
8-18
|
197
|
350
|
25
|
|
80
|
283
|
195
|
160
|
135
|
22
|
8-18
|
222
|
450
|
30
|
|
100
|
305
|
230
|
190
|
160
|
24
|
8-23
|
253
|
450
|
40
|
|
125
|
381
|
270
|
220
|
188
|
28
|
8-25
|
275
|
600
|
65
|
|
150
|
403
|
300
|
250
|
218
|
30
|
8-25
|
286
|
800
|
85
|
|
200
|
502
|
375
|
320
|
282
|
38
|
12-30
|
340
|
1200
|
100
|
|
250
|
568
|
445
|
385
|
345
|
42
|
12-34
|
470
|
1400
|
165
|
|
Q41F-64 Q41F-64P Q341F-64 Q341F-64P Q641F-64 Q641F-64P Q9B41F-64 Q9B41F-64P
|
|
15
|
165
|
105
|
75
|
55
|
18
|
4-14
|
105
|
130
|
3.1
|
|
20
|
190
|
125
|
90
|
68
|
20
|
4-18
|
125
|
130
|
4.9
|
|
25
|
216
|
135
|
100
|
78
|
22
|
4-18
|
135
|
160
|
7.2
|
|
32
|
229
|
150
|
110
|
82
|
24
|
4-23
|
150
|
160
|
8.7
|
|
40
|
241
|
165
|
125
|
95
|
24
|
4-23
|
165
|
230
|
12.1
|
|
50
|
292
|
175
|
135
|
105
|
26
|
4-23
|
175
|
230
|
16.7
|
|
65
|
330
|
200
|
160
|
130
|
28
|
8-23
|
200
|
400
|
28.2
|
|
80
|
356
|
210
|
170
|
140
|
30
|
8-23
|
210
|
400
|
36
|
|
100
|
432
|
250
|
200
|
168
|
32
|
8-25
|
250
|
700
|
66
|
|
125
|
508
|
295
|
240
|
202
|
36
|
8-30
|
295
|
1100
|
98
|
|
150
|
559
|
340
|
280
|
240
|
38
|
8-34
|
340
|
1500
|
142
|
Standard
Process
Trunnion-mounted ball valve
|
Main external and connection dimension
|
Unit:mm
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
L
|
D
|
D1
|
D2
|
b
|
Z-d
|
H
|
H1
|
Do
|
Q47F-16C Q67F-16C Q47F-16P Q347F-16C Q367F-16C Q347F-16P Q647F-16C Q667F-16C Q647F-16P
Q747F-16C Q767F-16C Q747F-16P Q9B47F-16C Q9B67F-16C Q9B47F-16P
|
|
50
|
178
|
160
|
125
|
100
|
16
|
4-18
|
177
|
120
|
|
15
|
|
65
|
191
|
180
|
145
|
120
|
18
|
4-18
|
190
|
140
|
|
19
|
|
80
|
203
|
195
|
160
|
135
|
20
|
8-18
|
210
|
150
|
|
27
|
|
100
|
229
|
215
|
180
|
155
|
20
|
8-18
|
235
|
172
|
|
38
|
|
125
|
356
|
245
|
210
|
185
|
22
|
8-18
|
350
|
215
|
|
58
|
|
150
|
394
|
280
|
240
|
210
|
24
|
8-23
|
530
|
250
|
|
81
|
|
200
|
457
|
335
|
295
|
265
|
26
|
12-23
|
620
|
290
|
600
|
140
|
|
250
|
533
|
405
|
355
|
320
|
30
|
12-25
|
650
|
320
|
600
|
160
|
|
300
|
610
|
460
|
410
|
375
|
30
|
12-25
|
780
|
360
|
600
|
205
|
|
350
|
686
|
520
|
470
|
435
|
34
|
16-25
|
790
|
395
|
800
|
260
|
|
400
|
762
|
580
|
525
|
485
|
36
|
16-30
|
920
|
450
|
800
|
390
|
|
450
|
864
|
640
|
585
|
545
|
40
|
20-30
|
970
|
490
|
800
|
510
|
|
500
|
914
|
705
|
650
|
608
|
44
|
20-34
|
1100
|
530
|
800
|
750
|
|
600
|
1067
|
840
|
770
|
718
|
48
|
20-41
|
1150
|
590
|
800
|
1200
|
|
700
|
1245
|
910
|
840
|
788
|
50
|
24-41
|
1850
|
700
|
800
|
2100
|
Main external and connection dimension Unit:mm
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
L
|
D
|
D1
|
D2
|
b
|
Z-d
|
H
|
H1
|
Do
|
Q47F-25 Q67F-25 Q47F-25P Q347F-25 Q747F-25 Q767F-25 Q747F-25P Q367F-25 Q347F-25P Q647F-25 Q947F-25 Q967F-25 Q667F-25 Q947F-25P Q647F-25P
|
|
|
|
50
|
216
|
160
|
125
|
100
|
20
|
4-18
|
177
|
120
|
|
20
|
|
65
|
241
|
180
|
145
|
120
|
22
|
8-18
|
190
|
140
|
|
25
|
|
80
|
283
|
195
|
160
|
135
|
22
|
8-18
|
210
|
150
|
|
30
|
|
100
|
305
|
230
|
190
|
160
|
24
|
8-23
|
235
|
172
|
|
40
|
|
125
|
381
|
270
|
220
|
188
|
28
|
8-25
|
350
|
215
|
|
65
|
|
150
|
403
|
300
|
250
|
218
|
30
|
8-25
|
530
|
250
|
|
85
|
|
200
|
502
|
360
|
310
|
278
|
34
|
12-25
|
620
|
290
|
600
|
100
|
|
250
|
568
|
425
|
370
|
332
|
36
|
12-30
|
650
|
320
|
600
|
182
|
|
300
|
648
|
485
|
430
|
390
|
40
|
16-30
|
780
|
360
|
600
|
212
|
|
350
|
762
|
550
|
490
|
448
|
44
|
16-34
|
790
|
395
|
800
|
288
|
|
400
|
838
|
610
|
550
|
505
|
48
|
16-34
|
920
|
450
|
800
|
468
|
|
450
|
914
|
660
|
600
|
555
|
50
|
20-34
|
970
|
490
|
800
|
587
|
|
500
|
991
|
730
|
660
|
610
|
52
|
20-41
|
1100
|
530
|
800
|
863
|
|
600
|
1143
|
840
|
770
|
718
|
56
|
20-41
|
1150
|
590
|
800
|
1396
|
|
700
|
1346
|
955
|
875
|
815
|
60
|
24-48
|
1850
|
700
|
800
|
2415
|
Forged trunnion-mounted ball valve
Main external and connection dimension Unit:mm
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
L
|
D
|
D1
|
D₂
|
b
|
Z-d
|
H
|
H₁
|
Do
|
QD47F-16C QD47F-16P QD347F-16C QD347F-16P
QD647F-16C QD647F-16P QD747F-16C QD747F-16P QD9B47F-16C QD9B47F-16P
|
|
50
|
178
|
160
|
125
|
100
|
16
|
4-18
|
160
|
85
|
|
28
|
|
65
|
191
|
180
|
145
|
120
|
18
|
4-18
|
170
|
95
|
|
32
|
|
80
|
203
|
195
|
160
|
135
|
20
|
8-18
|
200
|
110
|
|
44
|
|
100
|
229
|
215
|
180
|
155
|
20
|
8-18
|
210
|
120
|
|
86
|
|
125
|
356
|
245
|
210
|
185
|
22
|
8-18
|
350
|
215
|
|
133
|
|
150
|
394
|
280
|
240
|
210
|
24
|
8-23
|
530
|
190
|
|
203
|
|
200
|
457
|
335
|
295
|
265
|
26
|
12-23
|
575
|
230
|
-600
|
273
|
|
250
|
533
|
405
|
355
|
320
|
30
|
12-25
|
585
|
260
|
600
|
450
|
|
300
|
610
|
460
|
410
|
375
|
30
|
12-25
|
730
|
300
|
600
|
583
|
|
350
|
686
|
520
|
470
|
435
|
34
|
16-25
|
860
|
350
|
800
|
750
|
|
400
|
762
|
580
|
525
|
485
|
36
|
16-30
|
935
|
395
|
800
|
1190
|
|
450
|
864
|
640
|
585
|
545
|
40
|
20-30
|
975
|
440
|
800
|
2100
|
|
500
|
914
|
705
|
650
|
608
|
44
|
20-34
|
1060
|
485
|
800
|
3100
|
|
600
|
1067
|
840
|
770
|
718
|
48
|
20-41
|
1170
|
591
|
800
|
3980
|
|
700
|
1245
|
910
|
840
|
788
|
50
|
24-41
|
1270
|
686
|
800
|
4800
|
QD47/347/647/947F-25~64(P)
Main external and connection dimension Unit:mm
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
L
|
D
|
D1
|
D2
|
|
Z-d
|
H
|
H₁
|
Do
|
QD647F-25 QD47F-25 QD647F-25P QD47F-25P QD747F-25 QD347F-25 QD347F-25P
QD747F-25P QD947F-25 QD947F-25P
|
|
50
|
216
|
160
|
125
|
100
|
20
|
4-18
|
160
|
85
|
|
30
|
|
65
|
241
|
180
|
145
|
120
|
22
|
8-18
|
170
|
95
|
|
410
|
|
80
|
283
|
195
|
160
|
135
|
22
|
8-18
|
200
|
110
|
|
52
|
|
100
|
305
|
230
|
190
|
160
|
24
|
8-23
|
210
|
120
|
|
97
|
|
125
|
381
|
270
|
220
|
188
|
28
|
8-25
|
350
|
215
|
|
35
|
|
150
|
403
|
300
|
250
|
218
|
30
|
8-25
|
530
|
190
|
|
204
|
|
200
|
502
|
360
|
310
|
278
|
34
|
12-25
|
575
|
230
|
600
|
322
|
|
250
|
568
|
425
|
370
|
332
|
36
|
12-30
|
585
|
260
|
600
|
535
|
|
30C
|
648
|
485
|
430
|
390
|
40
|
16-30
|
730
|
300
|
60C
|
775
|
|
350
|
762
|
550
|
490
|
448
|
44
|
16-34
|
860
|
350
|
800
|
1210
|
|
400
|
838
|
610
|
55C
|
505
|
48
|
16-34
|
935
|
395
|
80C
|
2300
|
|
450
|
914
|
660
|
600
|
555
|
50
|
20-34
|
975
|
440
|
800
|
3400
|
|
500
|
991
|
730
|
660
|
610
|
52
|
20-41
|
1060
|
485
|
800
|
4208
|
|
600
|
1143
|
840
|
770
|
718
|
56
|
20-41
|
1170
|
591
|
800
|
5080
|
|
700
|
1346
|
955
|
875
|
815
|
60
|
24-48
|
1270
|
686
|
800
|
5750
|
Packing
Specification
API ball valve
Production enforce standard
Product
specification
|
Design spec
|
Face to face
|
Flange end
|
Test &check
|
Marking
|
Supply
|
API608
API6D
|
ANSI B16.10
API6D
|
ANSI B16.5
|
API598
API 6D
|
MSS SP-25
API 6D
|
API 608
API6D
|
Chief property and specification
|
Nominal pressure
|
150Lb
|
300Lb
|
400Lb
|
600Lb
|
|
Shell test pressure
|
3.1
|
7.5
|
10.2
|
15.0
|
|
Seal test
|
2.2
|
5.5
|
7.48
|
11.C
|
|
Seal test
|
0.5~0.7
|
|
Applicable medium
|
C
Water,oil,steam
|
P
Nitric acid
|
R
Acetic acid
|
Material for main parts
|
Parts name
|
WCB
|
CF8
|
CF3
|
CF8M
|
CF3M
|
|
Body &body cap
|
A216-WCB
|
A315-CF8
|
A35-CF3
|
A351-CF8M
|
A351-CE³M
|
|
Ball
|
B2-B8
|
A105-1025
|
A182-F304L
|
A182-F304L
|
A132-F316
|
A182-F316L
|
|
B8以上
|
A216-WCB
|
A351-CF8N
|
A351-CF3
|
A351-CF8M
|
A351-CF3M
|
|
Steam
|
A182-F6a
|
A182-F304
|
A182-F304L
|
A182-F336
|
A182-F316L
|
|
Seat
|
PTFE/Reinforced PTFE/Nyion
|
|
Ceat retaine
|
A105-1025
|
A182-F304
|
A182-F304L
|
A182-F316
|
A182-F316L
|
|
Spring
|
3yc-7/17-49H
|
|
O-ring
|
NBR
|
Viton
|
|
Stud
|
A193-B7
|
A193-B8
|
|
Nut
|
A194-2H
|
A194-8
|
A1-6B(3)41,(3)47,(3)61,(3)67F
Main external and connection dimension
|
CLASS 150 A1B(3)41,(3)47,(3)61,(3)67F(N.PPL).(P.R.V)
|
Unit:mm
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
Remark
|
|
d
|
L-RF
|
L-BW
|
D
|
D1
|
D2
|
|
|
N-中
|
H1
|
H2
|
Do
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4“
|
102
|
229
|
305
|
229
|
190.5
|
157
|
23.9
|
1.6
|
8-19
|
|
178
|
700
|
33.0
|
|
5"
|
127
|
356
|
|
254
|
216
|
186
|
23.9
|
1.6
|
8-22
|
|
252
|
100
|
58.0
|
|
6"
|
52
|
394
|
457
|
279
|
241.5
|
216
|
54.5
|
1.6
|
8-22
|
|
272
|
1100
|
93.0
|
|
8"
|
203
|
457
|
521
|
343
|
298.5
|
27(
|
58.6
|
1.6
|
8-22
|
|
342
|
500
|
60.C
|
|
8"
|
203
|
457
|
521
|
343
|
298.5
|
270
|
28.6
|
1.6
|
8-22
|
|
398
|
600
|
180.0
|
Fixing
ball
|
|
10“
|
254
|
533
|
559
|
406
|
362
|
324
|
30.2
|
1.6
|
12-25
|
335
|
495
|
600
|
240.0
|
|
12"
|
305
|
610
|
635
|
482.6
|
A31.8
|
381
|
31.8
|
1.6
|
2-25
|
385
|
580
|
80C
|
390.0
|
|
14"
|
337
|
686
|
762
|
535
|
476
|
412.8
|
35
|
1.6
|
12-29
|
430
|
625
|
800
|
510.0
|
|
16"
|
387
|
162
|
838
|
597
|
539.5
|
469.9
|
36.6
|
1.6
|
16-29
|
470
|
720
|
800
|
750.0
|
|
20”
|
489
|
914
|
991
|
698
|
635
|
58.2
|
42.9
|
1.6
|
20-32
|
590
|
840
|
800
|
1190
|
|
24"
|
591
|
1067
|
1143
|
813
|
749.5
|
692.2
|
47.8
|
1.6
|
20-35
|
700
|
1050
|
800
|
2100
|
|
26"
|
686
|
1245
|
1346
|
927.1
|
836.6
|
800.1
|
71.4
|
1.6
|
28-35
|
780
|
1150
|
800
|
3000
|
|
CLASS 300 A3B(3)41,(3)47,(3)67F(N.PPL).(P.R.V)
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
|
|
|
|
|
d
|
-RF
_
|
L-BW
|
D
|
D1
|
D2
|
|
|
N-φ
|
H1
|
H2
|
Do
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4"
|
102
|
305
|
305
|
254
|
200
|
157
|
31.8
|
1.6
|
8-22
|
|
178
|
700
|
55.0
|
|
5"
|
127
|
381
|
|
279
|
235
|
186
|
35
|
1.6
|
8-22
|
|
252
|
100
|
81.0
|
|
6"
|
52
|
403
|
457
|
318
|
270
|
216
|
36.5
|
1.6
|
12-22
|
|
272
|
1100
|
118.0
|
|
8"
|
203
|
502
|
521
|
381
|
330
|
270
|
41.3
|
1.6
|
12-25
|
|
342
|
500
|
200.00
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8"
|
203
|
502
|
521
|
381
|
330
|
270
|
41.3
|
1.6
|
12-25
|
|
398
|
600
|
220.2
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
10"
|
254
|
568
|
559
|
444
|
387.5
|
324
|
17.7
|
1.6
|
16-29
|
335
|
495
|
600
|
365
|
|
12"
|
305
|
648
|
635
|
520.8
|
451
|
381
|
50.8
|
1.6
|
6-32
|
385
|
580
|
800
|
530
|
|
14"
|
337
|
762
|
762
|
584.2
|
514.5
|
412.8
|
53.8
|
1.6
|
20-32
|
430
|
625
|
800
|
740
|
|
16"
|
387
|
838
|
838
|
647.8
|
571.5
|
469.9
|
57.2
|
1.6
|
20-35
|
470
|
720
|
800
|
1030
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
20"
|
489
|
991
|
991
|
774.8
|
685.8
|
58.2
|
63.5
|
1.6
|
24-35
|
590
|
840
|
800
|
1540
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
24"
|
591
|
143
|
143
|
914.4
|
812.8
|
692.2
|
69.8
|
1.6
|
24-41
|
700
|
1050
|
800
|
2600
|
|
28"
|
686
|
1346
|
1346
|
1035
|
939.8
|
800.1
|
85.9
|
1.6
|
28-44.5
|
780
|
150
|
800
|
3900
|
|
A1-6B(3)41,(3)47,(3)61,(3)67F
|
|
Main external and connection dimension
|
|
CLASS 400 A4B(3)41,(3)47,(3)67F(N.PPL).(P.R.V)
|
|
DN
|
Main external and connection dimension
|
|
|
d
|
L-RF
|
L-BW
|
|
|
|
|
|
|
4"
|
102
|
406
|
406
|
|
|
|
|
|
|
6“
|
152
|
495
|
495
|
|
|
|
|
|
|
8"
|
203
|
597
|
597
|
|
10"
|
254
|
673
|
673
|
|
|
|
|
|
|
12"
|
305
|
762
|
762
|
|
|
|
|
|
|
14"
|
337
|
826
|
826
|
|
|
|
|
|
|
16"
|
387
|
902
|
902
|
|
20”
|
489
|
1054
|
1054
|
|
|
|
|
|
|
24"
|
591
|
1232
|
1232
|
|
|
|
|
|
|
26”
|
686
|
1397
|
1397
|
|
CLASS 600 A6B(3)41,(3)47,(3)67F(N.PPL).(P.R.V)
|
|
Unit:mm
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
Remark
|
|
d
|
L-RF
|
L-BW
|
D
|
D1
|
D2
|
|
|
N-Φ
|
H1
|
H2
|
Do
|
|
4"
|
102
|
432
|
432
|
273
|
216
|
157.2
|
38
|
6.4
|
8-25
|
|
178
|
1100
|
76
|
|
6"
|
152
|
559
|
559
|
355.6
|
282.1
|
216
|
47.2
|
6.4
|
12-29
|
250
|
300
|
600
|
127
|
|
8"
|
203
|
660
|
660
|
419.5
|
349.2
|
269.8
|
55.7
|
6.4
|
12-32
|
294
|
374
|
800
|
350
|
Fixing
ball
|
|
10"
|
254
|
787
|
787
|
508
|
431.8
|
324
|
63.5
|
6.4
|
16-35
|
370
|
445
|
800
|
660
|
|
12"
|
305
|
838
|
838
|
559
|
489
|
381
|
66.5
|
6.4
|
20-35
|
420
|
515
|
800
|
820
|
|
14"
|
337
|
889
|
889
|
603.2
|
527
|
413
|
69.8
|
6.4
|
20-38
|
460
|
550
|
800
|
1130
|
|
16"
|
387
|
991
|
991
|
686
|
603.2
|
470
|
76.2
|
6.4
|
20-41
|
505
|
615
|
800
|
1550
|
|
20”
|
489
|
1194
|
1194
|
818
|
724
|
584.2
|
89
|
6.4
|
24-445
|
630
|
810
|
800
|
2800
|
|
24"
|
591
|
1394
|
1394
|
940
|
838.2
|
692.2
|
101.6
|
6.4
|
24-51
|
825
|
1010
|
800
|
5300
|
|
26”
|
686
|
1549
|
1549
|
1073
|
965.2
|
800
|
111.3
|
6.4
|
28-55
|
970
|
1180
|
800
|
6500
|
Floating ball valve
|
Main external and connection dimension
|
Unit:mm
|
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
L
|
D
|
D1
|
Dz
|
b
|
Z-d
|
H
|
W
|
|
Q41F-16C Q41F-16P Q641F-16C Q641F-16P Q9B41F-16C Q9B41F-16P
|
|
15
|
130
|
95
|
65
|
45
|
14
|
4-14
|
78
|
140
|
3
|
|
20
|
140
|
105
|
75
|
55
|
14
|
4-14
|
84
|
160
|
4
|
|
25
|
150
|
115
|
85
|
65
|
14
|
4-14
|
95
|
180
|
5
|
|
32
|
165
|
135
|
100
|
78
|
16
|
4-18
|
150
|
250
|
9
|
|
40
|
180
|
145
|
110
|
85
|
16
|
4-18
|
150
|
300
|
11
|
|
50
|
203
|
160
|
125
|
100
|
16
|
4-18
|
170
|
350
|
15
|
|
65
|
222
|
180
|
145
|
120
|
18
|
4-18
|
195
|
350
|
19
|
|
80
|
241
|
195
|
160
|
135
|
20
|
8-18
|
215
|
400
|
27
|
|
100
|
305
|
215
|
180
|
155
|
20
|
8-18
|
250
|
500
|
38
|
|
125
|
356
|
245
|
210
|
185
|
22
|
8-18
|
265
|
600
|
58
|
|
150
|
394
|
280
|
240
|
210
|
24
|
8-23
|
270
|
800
|
81
|
|
200
|
457
|
335
|
295
|
265
|
26
|
12-23
|
330
|
800
|
95
|
|
250
|
533
|
405
|
355
|
320
|
30
|
12-25
|
450
|
1300
|
140
|
Q41/341/641/941P-25~64(P)
Main external and connection dimension Unit:mm
|
DN
|
Main external and connection dimension
|
WT(Kg)
|
|
|
D
|
D1
|
D2
|
b
|
Z-c
|
H
|
W
|
|
Q41F-25 Q41F-25P Q641F-25 Q641F-25P Q9B41F-25 Q9B41F-25P
|
|
15
|
140
|
95
|
65
|
45
|
16
|
4-14
|
103
|
100
|
3
|
|
20
|
152
|
105
|
75
|
55
|
16
|
4-14
|
112
|
160
|
4
|
|
25
|
165
|
115
|
85
|
65
|
16
|
4-14
|
123
|
160
|
6
|
|
32
|
178
|
135
|
100
|
78
|
18
|
4-18
|
150
|
250
|
10
|
|
40
|
190
|
145
|
110
|
85
|
18
|
4-18
|
156
|
250
|
14
|
|
50
|
216
|
160
|
125
|
100
|
20
|
4-18
|
172
|
350
|
20
|
|
65
|
241
|
180
|
145
|
120
|
22
|
8-18
|
197
|
350
|
25
|
|
80
|
283
|
195
|
160
|
135
|
22
|
8-18
|
222
|
450
|
30
|
|
100
|
305
|
230
|
190
|
160
|
24
|
8-23
|
253
|
450
|
40
|
|
125
|
381
|
270
|
220
|
188
|
28
|
8-25
|
275
|
600
|
65
|
|
150
|
403
|
300
|
250
|
218
|
30
|
8-25
|
286
|
800
|
85
|
|
200
|
502
|
360
|
310
|
278
|
34
|
12-25
|
340
|
1200
|
100
|
|
250
|
568
|
425
|
370
|
332
|
36
|
12-30
|
470
|
1400
|
165
|
|
Q41F-40 Q41F-40P Q341F-40 Q341F-40P Q641F-40 Q641F-40P Q9B41F-40 Q9B41F-40P
|
|
15
|
140
|
95
|
65
|
45
|
16
|
4-14
|
103
|
100
|
3
|
|
20
|
152
|
105
|
75
|
55
|
16
|
4-14
|
112
|
160
|
|
|
25
|
165
|
115
|
85
|
65
|
16
|
4-14
|
123
|
160
|
6
|
|
32
|
178
|
135
|
100
|
78
|
18
|
4-18
|
150
|
250
|
10
|
|
40
|
190
|
145
|
110
|
85
|
18
|
4-18
|
156
|
250
|
14
|
|
50
|
216
|
160
|
125
|
100
|
20
|
4-18
|
172
|
350
|
20
|
|
65
|
241
|
180
|
145
|
120
|
22
|
8-18
|
197
|
350
|
25
|
|
80
|
283
|
195
|
160
|
135
|
22
|
8-18
|
222
|
450
|
30
|
|
100
|
305
|
230
|
190
|
160
|
24
|
8-23
|
253
|
450
|
40
|
|
125
|
381
|
270
|
220
|
188
|
28
|
8-25
|
275
|
600
|
65
|
|
150
|
403
|
300
|
250
|
218
|
30
|
8-25
|
286
|
800
|
85
|
|
200
|
502
|
375
|
320
|
282
|
38
|
12-30
|
340
|
1200
|
100
|
|
250
|
568
|
445
|
385
|
345
|
42
|
12-34
|
470
|
1400
|
165
|
|
Q41F-64 Q41F-64P Q341F-64 Q341F-64P Q641F-64 Q641F-64P Q9B41F-64 Q9B41F-64P
|
|
15
|
165
|
105
|
75
|
55
|
18
|
4-14
|
105
|
130
|
3.1
|
|
20
|
190
|
125
|
90
|
68
|
20
|
4-18
|
125
|
130
|
4.9
|
|
25
|
216
|
135
|
100
|
78
|
22
|
4-18
|
135
|
160
|
7.2
|
|
32
|
229
|
150
|
110
|
82
|
24
|
4-23
|
150
|
160
|
8.7
|
|
40
|
241
|
165
|
125
|
95
|
24
|
4-23
|
165
|
230
|
12.1
|
|
50
|
292
|
175
|
135
|
105
|
26
|
4-23
|
175
|
230
|
16.7
|
|
65
|
330
|
200
|
160
|
130
|
28
|
8-23
|
200
|
400
|
28.2
|
|
80
|
356
|
210
|
170
|
140
|
30
|
8-23
|
210
|
400
|
36
|
|
100
|
432
|
250
|
200
|
168
|
32
|
8-25
|
250
|
700
|
66
|
|
125
|
508
|
295
|
240
|
202
|
36
|
8-30
|
295
|
1100
|
98
|
|
150
|
559
|
340
|
280
|
240
|
38
|
8-34
|
340
|
1500
|
142
|
English
Español
Tel : +86-18565811709
Email :
